基于Bentley二次開發的污水廠改造“BIM+”集成技術
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第39卷 期數: 2023年第20期 頁碼: 77-82 欄目: 出版日期: 2023-10-17
Title:“BIM+” Integrated Technology for Reconstruction of Wastewater Treatment Plant Based on Bentley Secondary Development
作者:李文秋， 王曉杰， 徐亞男， 馬雪莉， 張博， 朱曉玉， 潘艷艷， 江燦（中國市政工程華北設計研究總院有限公司，天津 300074）
Author(s):LI Wen-qiu， WANG Xiao-jie， XU Ya-nan， MA Xue-li， ZHANG Bo， ZHU Xiao-yu， PAN Yan-yan， JIANG Can（North China Municipal Engineering Design ＆ Research Institute Co. Ltd.， Tianjin 300074， China）
關鍵詞:污水處理廠; Bentley; BIM; 二次開發
Keywords:wastewater treatment plant; Bentley; BIM; secondary development
摘要:李村河污水處理廠改造及四期擴建工程主要處理單元均采用全地下單層覆蓋建設模式，存在隱蔽性強、管線錯綜復雜及工期緊等設計難點問題。采用建筑信息模型（BIM）技術進行輔助設計，通過Bentley平臺二次開發，形成完善的圖庫及高效的污水廠建模工具庫，彌補了原生平臺的不足，提高了項目設計效率及設計質量，以自主開發編碼工具為媒介，推動了“BIM+智慧平臺”在該項目的應用，實現了資產高效運維，拓展了BIM技術的應用價值。
Abstract:The main treatment units of Licunhe wastewater treatment plant reconstruction and phase Ⅳ expansion project all adopt the underground single-layer coverage construction mode. There are several difficult problems in the design of the project, such as strong concealment, complicated pipeline and short construction period. Building information modeling (BIM) technology was employed to assist the design. A complete drawing library and an efficient wastewater treatment plant modeling tool library were formed through the secondary development of Bentley platform, which made up for the deficiencies of the original platform and improved the design efficiency and quality of the project. With the self-developed coding tool as the medium, the application of “BIM+ intelligent platform” in this project realized the efficient operation and maintenance of assets and expanded the application value of BIM technology.
